Specification:
Model | GLS-126000G | GLS-243000G | |
AC Input | Voltage | 100-240V AC | 100-240V AC |
Input current | 0.72A/230V AC | 0.72A/230V AC | |
Frequency | 47-63 Hz | 47-63 Hz | |
Efficiency | 82% typical | 85% typical | |
Inrush current | 36A/230V AC | 36A/230V AC | |
Leakage current | <0.5A/240V AC | <0.5A/240V AC | |
DC Output | Voltage | 12V | 24V |
Current | 0-5000mA | 0-2500mA | |
Rated Power | 60W | 60W | |
Ripple&noise | 120mvp-p | 150mvp-p | |
Setup rise hold up time | 500ms,20ms,50ms/230VAC 500ms,20ms,15ms/115VAC at full load | ||
Protection | Over Load | 120%Max, hiccup mode auto recovery after fault condition is removed | |
Short Circuit | Auto recovery | ||
Environment | Store Temperature | -20-85°C | |
Wokring Temperature | 0--50°C | ||
Operating Humidity | 20%-80%RH | ||
Safty | CE | Compliant to EN 60950-1:2006; EN61000-6-3:2001; | |
EN 55022:2006+A1:2007; EN61000-4-2/-3; | |||
EN61000-6-1:2001; EN55024:1998+A1:2000+A2:2003 | |||
RoHs | Free from lead, Cadmium, Mercury, Hexavalent | ||
Chromium and/or PBB &PBDE | |||
others | Product dimension | 138*58*33mm | |
Net Weight | 0.25kg/pc | ||
Packing | 50pcs/ctn, 44*38.5*16.5cm | ||
DC connector size | 5.5x2.1, 5.5x2.5. 3.5x1.35 or others | ||
Cable length | 1.2M or others |
Notes:
1.Voltage and current can be adjusted by customer requirement.
2.All parameters are specified at 230VAC input, rated load, 27°C 70%RH ambient.
